Application

Recreational or Commercial

Engine Connection

Direct or Remote (Jack or CV Shaft)

Exhaust

None through the sterndrive

Gear Ratios

1.24:1, 1.43:1, 1.52:1, 1.74:1, 1.94:1

Lubrication

Full Immersion, eighteen quarts with external reservoir

Propeller

Diameter Range - 15 in - 18.5 in (38 cm - 47 cm)

Rotation

Counter rotation

Steering Angle

50° range

Transmission

Reversing transmission required

Transom Mounting

Template available per application

Transom Requirements

13° angle nominal, 6.4 mm - 79.4 mm (1/4 in - 3 1/8 in) thick

Trim/Lift System

Approximate -6° to +10° trim, twin cylinders with electro-hydraulic pump Approximate 30° of total lift range
